Addressable Sounder FD7204 – UniPOS Bulgaria

FD7204 is applicable for sound and LED indication of events registered in Interactive Fire Alarm System IFS7000.
FD7204 is certified on EN54-3. The FD7204 sounder is connected to the signal loop of the IFS7002 panel, through the custom UniTalk protocol.

LEDs control:
Duty mode – The red  LED flash on a period of 16 sec. , if set  from panel;
Alarm mode –  The red   LED activated continuous ON with four diametrically located flashing leds flash on a period of 3 sec. ;
The flash / activation of the red LED is programmable from the IFS7002’s menus.

Technical parameters:
Maximum number of sounders in the IFS7002 signal loop:               25 pcs.
Voltage:                                                                                               15-30V DC
Current:                                                                                               8mA on 24 V DC      (on red led with
four diametrically located flashing leds )
Sound level, type “Slow whoop” on 1m:                                           80dB (А)
Frequency, pattern “Slow whoop”:                                                    0.5 – 1,2 kHz
Temperature:                                                                                      from minus 10°С to 50°С
Dimensions:                                                                                       (134x36x112)mm
Weight:                                                                                               0.140kg.
Protection:                                                                                          IPX2D
Construction:                                                                                      ABS
